Roll to Roll Galvo Laser Machine with Dual Scan Head
The ZJ(3D)-16080LDII is an industrial CO2 laser machine designed to deliver exceptional performance for various textile fabrics, technical textiles, non-woven materials, and industrial fabrics. This machine stands out with its dual galvanometer heads and cutting on-the-fly technology, which allows simultaneous cutting, engraving, perforating, and micro-perforating while the material is continuously fed through the system.
- Laser Type: CO2 RF Laser
- Laser Power: 300W × 2
- Working Area: 1600mm × 800mm
- Cutting Speed: 0 - 36,000 mm/min
Features
Discover the key advantages of our laser cutting systems, designed for precision, automation, and efficiency.
01
Simultaneous Dual-Galvo Scan Processing
Equipped with dual high-speed galvo heads that can operate simultaneously, enabling parallel processing and significantly increasing throughput without compromising precision.
02
Continuous Roll-to-Roll Automation
Seamlessly paired with an auto-correcting feeder and a rewinding unit, enabling fully automated, precise material alignment, continuous roll-to-roll processing without manual intervention.
03
Flying Optics for Large-Format Precision
Advanced flying optical path architecture enables high-speed processing over large working areas while maintaining consistent accuracy throughout the entire field.
04
CCD Vision System (Option)
High-resolution CCD camera system ensures accurate registration and alignment, ideal for contour cutting and precision pattern processing.
05
Industrial-Grade Control System
Built with a robust industrial control platform, offering strong anti-interference capability, stable operation, and reliable performance in demanding production environments.
Technical Specifications
Explore detailed specifications to better understand performance, speed, and compatibility.
| Model No. | ZJ(3D)-16080LDII | ||
|---|---|---|---|
| Laser Type | CO2 RF Metal Laser | ||
| Laser Power | 300W × 2 | ||
| Working Table | Chain Conveyor Working Table | ||
| Working Area | 1600mm × 800mm | ||
| Cutting Speed | 0 - 36,000 mm/min (Varies depending on material composition, thickness, and laser power) | ||
| Repeat Positioning Accuracy | ≤0.1 mm | ||
| Cooling System | Constant Temperature Water Chiller | ||
| Power supply | AC380V±5% 50/60Hz | ||
| Graphic format supported | AI, PLT, DXF, BMP, DST | ||
Application Sectors
Versatile Applications Across Multiple Industries and Materials Processing
Industries
Ideal for precision cutting, engraving, and perforation of fabrics used in garments such as sportswear, lingerie, activewear, and fashion apparel. Enables intricate patterns, breathable perforations, and consistent high-quality finishes.
Designed for processing high-performance materials used in outdoor gear, protective clothing, filtration media, and composite textiles, where precision and repeatability are critical.
Suitable for cutting and perforating automotive fabrics, seat covers, insulation materials, and decorative interior components, ensuring clean edges and uniform quality.
Perfect for curtains, upholstery fabrics, decorative panels, and soft furnishings, enabling customized patterns and high-end finishing effects.
Efficiently processes nonwoven fabrics and industrial flexible materials used in medical, hygiene, packaging, and filtration industries, supporting high-speed continuous production.
Compatible Materials
- Textile & Fabric
- Polyester
- Nonwoven
- Leather
- Aramid
- Kevlar®
- Cordura®
- Glass Fibre
- Synthetic Materials
Sample Gallery
Browse real samples produced by our systems to see the quality and versatility of laser cutting
Interested in this laser solution?
If you need any further information or a detailed estimate, do not hesitate to contact one of our experts who will offer you the solution that best suits your needs and will guide you through the purchase process.
